Object Scanner 3DMakerPro Lynx 3D Scanner
Large format — 200% larger capture area
Key features
- 250×400mm capture range (200% larger)
- Objects up to 5×5×5m
- Markerless visual tracking
- Optical stabilizer
- Up to 2,000,000 points per second
- Multiple modes: turntable, handheld, mobile
About this product
Lynx is a professional large-format 3D scanner designed for capturing medium to large objects with exceptional precision. Single capture range of 250×400mm — approximately 200% larger than traditional mid-format scanners. Users can digitize objects up to 5000×5000×5000mm: bodies, furniture, automotive components, sculptures.
Combines optical stabilization with visual tracking technology for smooth scanning of large objects without markers. Integrated software ecosystem (free JMStudio) provides automated model generation and one-click editing for art, design, and industrial applications.
Supports multiple scanning modes — turntable, handheld, mobile (with Connect accessory).
Specifications
| Accuracy | 0.10mm |
| Resolution | 0.30mm |
| Scan rate | 10 fps |
| Point distance | 0.30mm |
| Working distance | 400-900mm |
| Capture range | 250 × 400mm |
| Object size | 100-2000mm (up to 5000×5000×5000mm) |
| Light source | NIR (Near-Infrared) |
| Color | Optional color texture |
| Weight | 800g |
| Dimensions | 244 × 75 × 48mm |
| OS | Windows 10/11 64-bit, macOS 12/13 |
| Mobile | Android 10.0+, iOS 15.0+ (with Connect) |
| Output formats | OBJ, STL, ASC |
| Connectivity | USB 2.0 |
Ideal for
Automotive reverse engineering, sculptures, body, furniture, medical, forensics
